4-120 Wiring with Pico GFX-70
Circuit Diagram Symbols for Jumps
Function
If the jump coil is triggered, the circuit connections coming directly after it will
not be processed. The states of the coils before the jump will be retained,
unless they are overwritten in circuit connections that were not missed by the
jump. Jumps are always made forwards, i.e. the jump ends on the first contact
with the same number as that of the coil.
• Coil = jump when 1
• Contact only at the first left-hand contact position = Jump destination
The Jump contact point will always be set to 1
Contact
Make contact
(1)
(1) can only be used as first leftmost contact
:
Numbers 01 to 32
Coils [
Numbers 01 to 32
Coil function
[, ], , ,
IMPORTANT
Backward jumps are not possible with Pico GFX-70 due to
the way it operates. If the jump label does not come after
the jump coil, the jump will be made to the end of the
circuit diagram. The last circuit connection will also be
skipped.
If a jump destination is not present, the jump is made to the
end of the circuit diagram.
Multiple use of the same jump coil and jump contact is
possible as long as this is implemented in pairs, i.e.:
Coil
[
:1/jumped range/Contact:1,
Coil
[
:1/jumped range/Contact:1 etc.
