Publication 1760-UM002B-EN-P - March 2005
4-8 Wiring with Pico GFX-70
Incremental encoder counter function
block, actual value has exceeded
counter range (CARRY) CI X CY CI X CY X=01 … 02 4-85
Comparator function block,
less than
CP X LT CP X LT X=01 … 32 4-90
Comparator function block,
equal to
CP X EQ CP X EQ X=01 … 32 4-90
Comparator function block,
greater than
CP X GT CP X GT X=01 … 32 4-90
Text output function block D X Q1 D X Q1 X=01 … 32 4-92
Data function block DB X Q1 DB X Q1 X=01 … 32 4-93
PID controller, value range of
manipulated variable exceeded DC X LI DC X LI X=01 … 32 4-95
Receive a variable from a station (Get) GT X Q1 GT X Q1 X=01 … 32 4-95
Seven-day time switch HW X Q1 HW X Q1 X=01 … 32 4-106
Year time switch function block HY X Q1 HY X Q1 X=01 … 32 4-111
Master reset, sets all outputs and
markers to zero state MR X Q1 MR X Q1 X=01 … 32 4-122
Operating hours counter function
block, set time reached OT X Q1 OT X Q1 X=01 … 04 4-129
Operating hours counter, value
overflow (CARRY) OT X CY OT X CY X=01 … 04 4-129
Send a variable to the network,
enable active Put PT X Q1 PT X Q1 X=01 … 32 4-130
Pulse width modulation, error
minimum on or off time exceeded PW X E1 PW X E1 X=01 … 02 4-132
Send date and time via the Pico-Link
network function block SC X Q1 SC X Q1 X=01 4-135
Timing relay function block T X Q1 T X Q1 X=01 … 32 4-139
Table 4.2 Contacts
Contact Make
contact Break
contact Number Page
