Wiring with Pico GFX-70 4-61
Example:
Copy of marker blocks, definition of marker ranges direct
The content of marker bytes 10 to 19 is to be transferred to marker bytes 20 to
29.
Parameters of BT01 function block:
Source range:
>I1 MB10
Destination range:
>I2 MB20
Number of bytes:
>NO 10
After a rising edge from 0 to 1 at coil BT01T_ the content of MB10 to MB19
is copied to the marker bytes MB20 to MB29.
Example:
Copying of marker blocks, definition of a marker range with offset
The content of marker bytes MB15 to MB18 is to be copied to marker bytes
MB65 to MB68.
Source range Value of source
marker range
(decimal) Destination range Value of
destination
marker range
(decimal)
MB10 42 MB20 42
MB11 27 MB21 27
MB12 179 MB22 179
MB13 205 MB23 205
MB14 253 MB24 253
MB15 17 MB25 17
MB16 4 MB26 4
MB17 47 MB27 47
MB18 11 MB28 11
MB19 193 MB29 193
