Summary of changes, Catalog number release history – Rockwell Automation 1760-xxxx Pico GFX-70 Controllers User Manual User Manual
Page 3
3
Publication 1760-UM002B-EN-P - March 2005
Summary of Changes
The information below summarizes the changes to this manual since the last
release as publication 1760-UM002A-EN-P, April 2004.
To help you locate new and updated information in this release of the manual,
we have included change bars as shown to the right of this paragraph.
Catalog Number Release
History
The following table shows the history of the Pico GFX-70 catalog numbers.
Released April 2004
Released April 2005
GFX I/O Modules
1760-IB12XOW4IF
1760-IA12XOW4I
1760-IB12XOW4IOF
1760-IB12XOB4IF
1760-IB12XOB4IOF
Expansion I/O Modules
1760-IA12XOW6I
1760-IB12XOW6I
1760-IB12XOB8
1760-OW2
Processor Units
1760-LDF
1760-LDFA
1760-LDFC
1760-LDFCA
1760-RM-GFX
Programming Software and Cable
1760-PICOSOFTPRO
1760-CBL-PC02
1760-PICOPRO-PC02
Display Units
1760-DUB
1760-DU
Memory Module
1760-MM3
Power Supply
1606-XLP30E
Point-to-Point Serial Interface Cables
1760-CBL-2M
1760-CBL-5M
Cables for Pico-Link between Processors
1760-CBL-INT01
1760-CBL-INT03
1760-CBL-INT05
1760-CBL-INT300
1760-CONN-RJ45
1760-TERM1
