1

Publication 1760-UM002B-EN-P - March 2005

Chapter

3

Commissioning

Switching On

Before startup check whether the power supply, inputs, outputs, the
serial interface and the Pico-Link cable are properly connected:

• 24V dc version:

–

Terminal +24V: +24V voltage

–

Terminal 0V: 0V voltage

–

Terminals I1 to I12, R1 to R12:
Actuation via +24V

• 230V ac version

–

Terminal L: Phase conductor L

–

Terminal N: Neutral conductor N

–

Terminals R1 to R12:
Actuation via phase conductor L

If you have already integrated devices into a system, secure any parts
of the system connected to the working area to prevent access and
ensure that no-one can be injured if, for example, motors start up
unexpectedly.

Setting the Menu Language

When you switch on the Pico GFX-70 for the first time, you will be asked to
select the menu language.

1.

Use the up and down arrow buttons to select the language
required.

–

English

–

German

–

French

–

Spanish

–

Italian

–

Portuguese

–

Dutch

–

Swedish

–

Polish

–

Turkish

ENGLISH

✓

DEUTSCH

FRANCAIS

ESPANOL
