8. Select the REMOTE MARKER menu item.
The following selection will only be displayed if the Serial Interface
menu item has been ticked.
9. Press the OK button.
The data is physically located in the second station, i.e. the remote
station.
The following marker ranges can be selected:
1MD1 to 1MD20
This corresponds to the following range in the remote station:
MD1 to MD20
BAUDRATE:19200B
Serial Interface
✓
REMOTE MARKER...
READ:
1MD00 Ç 1MD00
WRITE:
1MD00 Ç 1MD00
IMPORTANT
The active station reads and writes data from and to
the markers of the remote station. At the same time,
the remote station has read and write access to the
same marker range.
Ensure that both stations do not have write access to
the same markers simultaneously. The last write
operation will be the one that is retained.
Example:
READ 1MD2 -> 1MD2
WRITE 1MD3 -> 1MD3
The GFX device accesses the markers with station
address 1xx... These markers correspond to the local
markers MD2 and MD3 in the remote station.
These marker double words contain:
MD2, MW3, MW4, MB5; MB6, MB7, MB8, M33 to
M64
MD3, MW5, MW6, MB9, MB19, MB11, MB12; M65 to
M96
