6-4 Pico-Link and Point-to-Point Serial Connections
Position and Addressing of the Operands via the Pico-Link
Stations
Basic unit
Local expansion
Network bit data
Network word data
Input
Output
Input
Output
Input
Output
Receive
Send
I
Q
R
S
RN
SN
1
1 I 1 to 16
1 Q 1 to 8
1 R 1 to 16 1 S 1 to 8
2 to 8 RN 1 to 32
2 to 8 SN 1 to 32
GT 1 to 32
PT 1 to 32
2
2 I 1 to 16
2 Q 1 to 8
2 R 1 to 16 2 S 1 to 8
1, 3 to 8 RN 1 to 32
1, 3 to 8 SN 1 to 32
GT 1 to 32
PT 1 to 32
3
3 I 1 to 16
3 Q 1 to 8
3 R 1 to 16 3 S 1 to 8
1, 2, 4 to 8 RN 1 to 32
1, 2, 4 to 8 SN 1 to 32
GT 1 to 32
PT 1 to 32
4
4 I 1 to 16
4 Q 1 to 8
4 R 1 to 16 4 S 1 to 8
1 to 3, 5 to 8 RN 1 to
32
1 to 3, 5 to 8 SN 1 to
32
GT 1 to 32
PT 1 to 32
5
5 I 1 to 16
5 Q 1 to 8
5 R 1 to 16 5 S 1 to 8
1 to 4, 6 to 8 RN 1 to
32
1 to 4, 6 to 8 SN 1 to
32
GT 1 to 32
PT 1 to 32
6
6 I 1 to 16
6 Q 1 to 8
6 R 1 to 16 6 S 1 to 8
1 to 5, 7, 8 RN 1 to 32
1 to 5, 7, 8 SN 1 to 32
GT 1 to 32
PT 1 to 32
7
7 I 1 to 16
7 Q 1 to 8
7 R 1 to 16 7 S 1 to 8
1 to 6, 8 RN 1 to 32
1 to 6, 8 SN 1 to 32
GT 1 to 32
PT 1 to 32
8
8 I 1 to 16
8 Q 1 to 8
8 R 1 to 16 8 S 1 to 8
1 to 7 RN 1 to 32
1 to 7 SN 1 to 32
GT 1 to 32
PT 1 to 32
IMPORTANT
The RN-SN connection is a point-to-point connection
between the stations indicated. With RN and SN the
number of the contact must have the same number
as the coil. Example: 2SN30 from station 8 is sent to
8RN30 of station 2.
