A-2 Specifications
Table A.2 Protective Membrane Mounting Specifications
Specification 1760-NDM
Dimensions (W x H x D) 88.5 mm x 88.5 mm x 22.5 mm
(3.49 x 3.49 x 0.99)
Weight 25g (0.055 lb)
Mounting Is fitted over the display/keypad (with front
ring)
Table A.3 Protective Cover Mounting Specifications
Specification 1760-NDC
Dimensions (W x H x D) 86.5 mm x 95 mm x 25 mm
(3.41 in x 3.74 in x 0.99 in)
Weight 36g (0.079 lb)
Mounting Is fitted over the display/keypad (without
front ring)
Table A.4 Processor Mounting Specifications
processor unit 1760-LDF and 1760-LDFC
1760-LDFA and 1760-LDFCA
Dimensions (W x H x D) 107.5 mm x 90 mm x 30 mm
(4.23 in x 3.54 in x 1.18 in)
Weight 145g (0.32 lb)
Mounting Fitted on the fixing shaft of the display or
on the DIN rail to DIN 50022, 35mm
(without display) or by means of fixing feet
(without display)
Table A.5 I/O Modules Mounting Specifications
Specification 1760-IA12XOW4I
1760-IB12XOW4IF
1760-IB12XOW4IOF 1760-IB12XOB4IF
1760-IB12XOB4IOF
Dimensions when fitted (W x H x D) 88.1 mm x 90 mm x 25 mm
(3.47 in x 3.55 in x 0.99 in)
Dimensions when removed (W x H x D) 88.1 mm x 90 mm x 44 mm
(3.47 in x 3.55 in x 1.73 in)
Weight 150g (0.33 lb) 140g (0.32 lb)
Mounting Snap fitted into the processor unit
