Wiring with Pico GFX-70 4-29
Calling the Function Blocks via the FUNCTION RELAYS Menu
Figure 4.15 Explanation of the function block display
Display of the Function Blocks for Editing
Figure 4.16 Function block display during editing
Editing Function Blocks
1. Go to the FUNCTION RELAYS menu.
2. Press the OK button.
The following display appears if no function blocks are present.
The cursor flashes.
3. Press the OK button.
❚ ❚ ❚ ❚ ❚ ❚ ❚ ❚ ❚ ❚ ❚
❚ ❚ ❚ ❚ ❚ ❚ ❚
❚ ❚ ❚ ❚
L:001 B:
❚ ❚ ❚ ❚
Displays the
function
blocks used
Function, special function,
parameter display
Free memory in bytes
Current
cursor line
❚ ❚ ❚ ❚ ❚ ❚ ❚ ❚ ❚ ❚ ❚
>I1
❚ ❚ ❚ ❚ ❚ ❚ ❚ ❚ ❚ ❚ ❚
>I2
❚ ❚ ❚ ❚ ❚ ❚ ❚ ❚ ❚ ❚ ❚
QV>
❚ ❚ ❚ ❚ ❚ ❚ ❚ ❚ ❚ ❚ ❚
Parameter display
(+ appears/
- does not appear)
Unit/special function
Function block number
Function block name
Function block inputs
Function block outputs
Variable, operand for outputs
Variable, operand for
inputs
Function
z z
L:001 B:7898
