Page 83

Publication 1760-UM002B-EN-P - March 2005
Commissioning 3-5
Starting Point Status Display
When you switch on Pico GFX-70, it opens the Status display immediately to
show the switching state of the inputs and outputs. It also indicates whether
the processor is already running a program. Note: If another display is visible,
a visualization screen is shown.
In this case Pico GFX-70 must be in STOP mode.
1.
Press OK to switch to the main menu.
2.
Press OK to switch to the next menu level, and press ESC to move one
level back.
3.
Press OK twice to enter the circuit diagram display via menu items
PROGRAM…
−−> PROGRAM. This is where you will create the circuit
diagram.
I ............
I
P-
MO 02:00
Q........
STOP
TIP
The examples were written without the use of
expansion units. If an expansion unit is connected,
the Status display will first show the status of the
basic unit and then the status of the expansion unit
before showing the first selection menu.
PROGRAM...
STOP
✓
RUN
PARAMETERS
SET CLOCK...
TIP
OK
has two other functions:
• Press OK to save modified settings.
• In the circuit diagram, you can also press OK to
insert and modify contacts and relay coils.
CIRCUIT DIAGRAM
FUNCTION RELAYS
