Publication 1760-UM002B-EN-P - March 2005
Wiring with Pico GFX-70 4-93
Contacts
A contact has been assigned to the text output function block.
D01Q1 to D32Q1, text function block is active.
Coils
D01EN to D32EN, enable of the text function block
Memory Requirement of the Text Output Function Block
The text output function block function block requires 160 bytes of memory.
This is irrespective of the text size.
Data Function Block
The data function block allows you to selectively save a value. Setpoint values
for the function block can be saved in this manner.
Figure 4.39 Pico GFX-70 circuit diagram with data function block:
Parameter display and parameter set for the data function block:
Inputs
The function block input
>I1
can be assigned the following operands:
• Constants
• Markers MD, MW, MB
• Analog inputs IA01 to IA04
– IA01: terminal I7
– IA02: terminal I8
GT01Q1---------------------------[ DB16T
DB16Q1---------------------------S D 02EN
DB16 +
>I1
QV>
DB16 Data block function block number 16
+ Appears in the parameter display
>I1 Input value
QV> Actual value
