Wiring with Pico GFX-70 4-39
– single pulse
– synchronous flashing
– asynchronous flashing
• Set cycle time
• Value limitation
The following applies to function blocks:
IMPORTANT
The most recent actual values are cleared if the power
supply is switched off or if Pico GFX-70 is switched to
STOP mode. Exception: Retentive data keeps its state (see
Retention on page 7-22).
The most recent actual values are transferred to the
operands every cycle. The data function block is an
exception.
ATTENTION
The following applies to RUN mode: Pico GFX-70
processes the function block after a pass through the circuit
diagram. The last state of the coils is used for this.
IMPORTANT
If you want to prevent other people from modifying the
parameters, change the access enable symbol from “+” to
“-” when creating the circuit diagram and setting
parameters and protect the circuit diagram with a password.
