Deleting the circuit diagram, Fast circuit diagram entry – Rockwell Automation 1760-xxxx Pico GFX-70 Controllers User Manual User Manual
Page 91

Publication 1760-UM002B-EN-P - March 2005
Commissioning 3-13
Deleting the Circuit Diagram
1.
Switch the Pico GFX-70 to STOP mode.
2.
Use PROGRAM… to switch from the main menu to the next menu
level.
3.
Select DELETE PROGRAM
The Pico GFX-70 will display the prompt DELETE?
4.
Press OK to delete the program or ESC to cancel.
5.
Press ESC to return to the Status display.
Fast Circuit Diagram Entry
You can create a circuit diagram in several ways: The first option is to enter the
elements in the circuit and then to wire all the elements together. The other
option is to use the enhanced operator guidance of Pico GFX-70 and create
the circuit diagram in one go, from the first contact through to the last coil.
If you use the first option, you will have to select some of the elements in
order to create and connect up your circuit diagram.
The second, faster option is what you learned in the example. In this case you
create the entire circuit connection from left to right.
IMPORTANT
Pico GFX-70 must be in STOP mode in order to extend,
delete or modify the circuit diagram.
PROGRAM...
DELETE PROGRAM
