Publication 1760-UM002B-EN-P - March 2005
3-32 Commissioning
2. Close Terminal mode.
3. Press the * button to close the Terminal mode.
4. Press the * button.
This returns you back to your local device.
5. Press the ESC button twice.
The Status display is active.
The flashing star at the top right of the display is no longer present.
IMPORTANT
In Terminal mode, the GFX device makes its display
and keypad available to the connected device. Only
data for the display and the status of the buttons is
sent via the connection. This ensures that the local
data of the connected device is not destroyed in the
event of a communication fault.
STATION ID: 2
START MODE
IMPORTANT
The * button cannot be assigned to other tasks if you
wish to use Terminal mode in your application. Use
the * button to change from the visualization to the
Status display. Otherwise the Terminal mode menu
cannot be reached.
STATION ID: 2
START MODE
I ..345..89...
I P-
SA 06:47 ST
Q 2 4 STOP
TIP
The display must be initialized again if the processor was
fitted to it under live conditions.
Press the DEL and ESC buttons simultaneously to
reinitialize the display.
