Publication 1760-UM002B-EN-P - March 2005
Summary of Changes 4
New Information The following table lists the sections of this manual where new information
has been added.
Protective Covers
1760-NDM
1760-NDC
Mounting Feet
1760-NMF
Tools
1492-N90
1492-KWC
Released April 2004 Released April 2005
For this New Information See
Added Figure 1.3, Remote Processor Features. 1-5
Revised Catalog Number Reference section to include new catalog numbers. 1-6
Revised Setting Values section. 1-19
In the section, Connecting the Expansion Unit, added a note that you can
only connect one expansion I/O module to each controller. 2-16
Modified text below Figure 2.28, Temperature sensor, brightness sensor, 20
mA sensor. 2-26
Added new catalog numbers to Table 2.47, Pico Expansion I/O Modules. 2-40
Added Installing the Remote Processor section. 2-41
Re-arranged the numbered steps within the Starting Point Status Display
section. 3-5
Added TIP on how to reinitialize the display. 3-32
Added IMPORTANT note about only writing the markers once. 4-14
Modified text in the High-Speed Functions section. 4-74
Added IMPORTANT in the Function of the GET Function Block section. 4-106
Modified text within the Function of the Year Time Switch Function Block
section. 4-113
Added text within the Accuracy section. 4-130
Modified text within the IMPORTANT statement. 4-135
Changed value for seconds time range in Table 4.65, Time Range. 4-141
Modified and added text within the Variable Setpoint Values section. 4-142
Modified title for Figure 4.68, Signal diagram of timing relay, off-delayed
(with/without random switching with/without retriggering). 4-146
Modified title for Figure 4.69, Signal diagram of timing relay, off-delayed
(with/without random switching with/without retriggering). 4-147
Totally new version of Chapter 5, Visualization with Pico GFX-70. 5-1
