Publication 1760-UM002B-EN-P - March 2005
Pico GFX-70 Settings 7-11
Setting Date, Time and
Daylight Savings Time The devices are equipped with a real-time clock with date and time functions.
The “time switch” function block can be used to implement time switch
applications.
If the clock has not yet been set or if Pico GFX-70 is switched on after the
buffer time has elapsed, the clock starts with the setting “WE 1:00
01.05.2002”. The Pico GFX-70 clock operates with date and time so the hour,
minute, day, month and year must all be set.
1. Select SET CLOCK… from the main menu.
This will open the menu for setting the time.
2. Select SET CLOCK.
3. Set the values for day, time, month and year.
4. Press the OK button to access the Entry mode.
– Use the left/right arrow keys to move between the parameters
– Use the up/down arrow keys to change the value.
– OK Save day and time
– ESC Retain previous setting.
5. Press ESC to leave the time setting display.
IMPORTANT
The time, such as: 1:00, indicates the version of the device
operating system.
SET CLOCK
DST SETTING
HH:MM 00:27
DD.MM 05.05
YEAR : 2002
