Publication 1760-UM002B-EN-P - March 2005
A-12 Specifications
AC-15 250V ac, 3A (600 Ops/h) 300,000 switch operations
DC-13 L/R ≤ 150 ms 24V dc, 1A (500 Ops/h) 200,000 switch operations
Filament lamp load
1000 W at 230/240V ac 25,000 switch operations
500 W at 115/120V ac 25,000 switch operations
Fluorescent tube with ballast, 10 x 58 W at 230/240V ac 25,000 switch operations
Conventional fluorescent tube, compensated, 1 x 58 W at 230/240V ac 25,000 switch operations
Conventional fluorescent tube, uncompensated, 10 x 58 W at 230/240V ac 25,000 switch operations
Operating frequency, relays
Mechanical switch operations
10 million (10 7 ) switch operations
Mechanical switching frequency 10 Hz
Resistive lamp load 2 Hz
Inductive load 0.5 Hz
Table A.11 GFX I/O Modules Relay Output Specifications
Specification 1760-IA12XOW4I, 1760-IB12XOW4IF
1760-IB12XOW4IOF, 1760-OW2
Table A.12 UL/CSA Relay Ratings
Uninterrupted current at 240V ac/24V dc 10A/8A
AC Control Circuit Rating Codes (utilization category) B300 Light Pilot Duty
Max. rated operational voltage 300V ac
Max. thermal uninterrupted current cos
ϕ = 1
at B300
5A
Maximum make/break capacity cos
ϕ k 1 (Make/break) at B300
3600 VA/360 VA
DC Control Circuit Rating Codes (utilization category) R300 Light Pilot Duty
Max. rated operational voltage 300V dc
Max. thermal uninterrupted current at R300 1A
Maximum make/break capacity at R300 28 VA/28 VA
