4-26 Wiring with Pico GFX-70
The subsequent circuit connection(s) will be “pulled up” and any
existing links between circuit connections will be retained.
Switching Via the Cursor Buttons
With Pico GFX-70, you can also use the four cursor buttons as hard-wired
inputs in the circuit diagram.
The buttons are wired in the circuit diagram as contacts
P 01
to
P 04
. The P
buttons can be activated and deactivated in the h System menu.
The P buttons can also be used for testing circuits or manual operation. These
button functions are also useful for servicing and commissioning purposes.
Example 1
A lamp at output Q1 is switched on and off via inputs I1 and I2 or by using
the up/down arrow buttons.
Figure 4.11 Switch Q1 via I1, I2, or the up/down arrow buttons
Example 2
Input I1 is used to control output Q1. I5 switches over to cursor operation and
via
m 01
disconnects the circuit connection
I 01
.
Figure 4.12 I5 switches over to the cursor buttons.
OK
P2
P4
P1 P3
IMPORTANT
The P buttons are only detected as switches in the Status
menu.
I 01--|------------------------S Q 01
P 02--
|
I 02--|------------------------R Q 01
P 04--
|
I 05---------------------------S M 01
I 01----M 01--|----------------S Q 01
P 01----M 01--
|
