Wiring with Pico GFX-70 4-19
A contact of a function relay is assigned the name of the function block, the
number and the contact function.
Example: contact of comparator function block
If the contact on a network station is used, the address of the station is placed
before the contact name.
Example: contact of a Pico-Link station
Coils
With a relay coil or function block select the coil function, coil or function
block name, coil or function block number as well as coil of the function
block. With coils of a Pico-Link network station, the network address is
selected before the coil name.
Example: relay coil output
Relay coil for timing relay function block with control coil
Relay coil of a Pico-Link station
A full list of all the contacts and relays is given in the overview starting on page
4-4.
CP 01 GT
Contact name
Contact number
Contact function
2RN 02
Station address
Contact name
Contact number
S Q 04
Coil function
Coil name
Coil number
[ T 04 EN
Coil function
Coil name
Coil number
Function block coil
S2 SN 04
Coil function
Station address
Coil number
Coil name
