Publication 1404-UM001D-EN-E - October 2004
Powermonitor 3000 Operations 3-21
Configuration Using the
Display Module The Display Module provides an inexpensive, easy-to-operate method
for setting up Powermonitor 3000 parameters to adapt it to your
power system and select the performance options you desire. You
configure the Powermonitor 3000 using Program Mode and Edit Mode
of the Display Module. Once you have become familiar with the key
functions, you will find that setting up a new Powermonitor 3000 is a
simple process.
You may also configure the Powermonitor 3000 via communications,
and certain advanced features of the Powermonitor 3000 may be
configured only via communications. Please refer to the appropriate
sections of the User manual for more information.
Table 3.6 Commands
Parameter Description Range
Force Relay Forces relay to a known state in which the relay
remains at that state until the force is removed. De-energize
Energize
No Force
Force KYZ Forces KYZ to a known state in which the relay
remains at that state until the force is removed. De-energize
Energize
No Force
Clear Min/Max Log Resets the Min/Max log with the current real
time metering information. Yes
No
Clear kWh Counter Resets the kWh net counter to zero. Yes
No
Clear kVARh Counter Resets the kVARh net counter to zero. Yes
No
Clear kVAh Counter Resets the kVAh net counter to zero. Yes
No
Clear Ah Counter Resets the Ah net counter to zero. Yes
No
Clear All Energy Counters Resets all cumulative energy counter to zero. Yes
No
Clear S1 Counter Resets Status 1 counter to zero. Yes
No
Clear S2 Counter Resets Status 2 counter to zero. Yes
No
Restore Defaults Settings Restores all settings to factory default. Yes
No
Clear Setpoint Timers Clears the time accumulated in each setpoint
timer. Yes
No
