Rockwell Automation 1404-M4_M5_M6_M8 Powermonitor 3000 User Manual, PRIOR to Firmware rev. 3.0 - Manual (Page 192)

Publication 1404-UM001D-EN-E - October 2004
A-18 Powermonitor 3000 Data Tables
Table A.10 Metering Sequence Voltage and Current Results
CSP File No. F16
Remote I/O BT 27
CIP Assy. Inst. 15
No. of Elements 11
User Configurable No
Data Type Floating point
Data Access Read only
PM3000 Type All
Element
No. Modbus
Address Element name Units Range Comment
0 30201-02 L4 (Zero sequence) Current Amps (A)
0.0 to 999.9x10
21 Refer to Symmetrical Component Analysis
Results on page 3-5.
1 30203-04 Positive Sequence Current
0.0 to 999.9x10
21
2 30205-06 Negative Sequence Current
0.0 to 999.9x10
21
3 30207-08 % Current unbalance Per Cent 0.0 to 100.0
4 30209-10 Positive Sequence Voltage Volts (V)
0.0 to 999.9x10
21
5 30211-12 Negative Sequence Voltage
0.0 to 999.9x10
21
6 30213-14 % Voltage unbalance Per Cent 0.0 to 100.0
7 30215-16 Phase rotation - 0 to 2 0 = No rotation
1 = ABC rotation
2 = ACB rotation
8 30217-18 Average frequency Hertz (Hz) 40.0 to 75.0 Average of the last 1 or 8 cycles.
Returns 0 or 999.0 if out of range
9 30219-20 Frequency source - 0 to 2 0 = V1, 1 = V2, 2 = V3
10 30221-22 Metering iteration - 0 to 32767 Increments by 1 to 32767, rolls over to 0
