Publication 1404-UM001D-EN-E - October 2004
A-20 Powermonitor 3000 Data Tables
Table A.12 Metering Demand Results
CSP File No. F18
Remote I/O BT 25
CIP Assy. Inst. 17
No. of Elements 10
User Configurable No
Data Type Floating point
Data Access Read only
PM3000 Type All
Element
No. Modbus
Address Element name Units Range Comment
0 30401-02 Demand Current Amps (A)
0.0 to 999.9x10
21 Refer to Energy Results on page 3-8.
1 30403-04 Demand Power Watts (W) 0.0 to 999.9x10 21
2 30405-06 Demand Reactive Power VAR
0.0 to 999.9x10
21
3 30407-08 Demand Apparent Power VA
0.0 to 999.9x10
21
4 30409-10 Projected Demand I Amps
0.0 to 999.9x10
21 Refer to Projected Demand Calculation on page 3-10.
5 30411-12 Projected Demand W Watts
0.0 to 999.9x10
21
6 30413-14 Projected Demand VAR VAR
0.0 to 999.9x10
21
7 30415-16 Projected Demand VA VA
0.0 to 999.9x10
21
8 30417-18 Elapsed demand period time Minutes
0.0 to 999.9x10
21 The time elapsed within the current demand period.
9 30419-20 Metering iteration - 0 to 32767 Increments by 1 to 32767, rolls over to 0
