Rockwell Automation 1404-M4_M5_M6_M8 Powermonitor 3000 User Manual, PRIOR to Firmware rev. 3.0 - Manual (Page 218)

Publication 1404-UM001D-EN-E - October 2004
A-44 Powermonitor 3000 Data Tables
Table A.34 Harmonic Results; THD, Crest Factor, and More
CSP File No. F34
Remote I/O BT 23
CIP Assy. Inst. 41
No. of Elements 9 (M4, M5); 10 (M6, M8)
User Configurable No
Data Type Floating Point
Data Access Read only
PM3000 Type See table
Element
No. Modbus
Address M4
M5 M
6 M
8 Element name Range Comment
0 31201-02
• • • Channel number
1 to 9 Refer to Reading Harmonic Analysis Data on page 8-11
1 31203-04
• • • % IEEE THD
0.0 to 1000.0
2 31205-06
• • • % IEC thd (DIN)
0.0 to 1000.0
3 31207-08 • • • Crest Factor 0.0 to 10.0
4 31209-10 • • • THD & Crest iteration 0 to 32767
5 31211-12 • Reserved 0
• • TIF
0.0 to 999.9x10
22
6 31213-14
•
Reserved 0
• • K-Factor
0.0 to 999.9x10
22
7 31215-16
•
Reserved 0
• • IEEE-519 TDD
0.0 to 999.9x10
22
8 31217-18
•
Reserved 0
• • IEEE-519 Pass/Fail -1 to 1
9 31219-20 • Reserved 0
• • FFT iteration
0 to 32767
