Rockwell Automation 1404-M4_M5_M6_M8 Powermonitor 3000 User Manual, PRIOR to Firmware rev. 3.0 - Manual (Page 208)

Publication 1404-UM001D-EN-E - October 2004
A-34 Powermonitor 3000 Data Tables
Table A.24 Min/Max Log Parameter List
Applies to: Table 23: Min/max log config. / read-back select
Table 25: Min/max log results
PM3000 Type All
Param
No. Parameter name Comment
0 L1 Current Refer to Table A.9 Metering Voltage, Current and Frequency Result
1 L2 Current
2 L3 Current
3 Avg Current
4 L1-N Voltage
5 L2-N Voltage
6 L3-N Voltage
7 Avg L-N Voltage
8 L1-L2 Voltage
9 L2-L3 Voltage
10 L3-L1 Voltage
11 Avg L-L Voltage
12 Frequency, last cycle
13 L4 Current Refer to Table A.10 Metering Sequence Voltage and Current Results
14 Positive Sequence Current
15 Negative Sequence Current
16 % Current unbalance
17 Positive Sequence Voltage
18 Negative Sequence Voltage
19 % Voltage unbalance
20 Average frequency
21 L1 Real Power Refer to Table A.11 Metering Power Results
22 L2 Real Power
23 L3 Real Power
24 Total Real Power
25 L1 Reactive Power
26 L2 Reactive Power
27 L3 Reactive Power
28 Total Reactive Power
29 L1 Apparent Power
30 L2 Apparent Power
31 L3 Apparent Power
32 Total Apparent Power
