Publication 1404-UM001D-EN-E - October 2004
A-48 Powermonitor 3000 Data Tables
Table A.38 Harmonic Results; Even Harmonics 22 to 40
CSP File No. F38
Remote I/O BT 42
CIP Assy. Inst. 45
No. of Elements 14
User Configurable No
Data Type Floating Point
Data Access Read only
PM3000 Type M6, M8 only
Element
No. Modbus
Address Element name Range Comment
0 - Channel # returned 1 to 7 Refer to Reading Harmonic Analysis Data on
page 8-11
1 - Type of harmonic data returned 0 to 1
2 - Reserved 0
3 -
22
nd
Harmonic 0.0 to 999.9x10
22
4 -
24
th
Harmonic 0.0 to 999.9x10
22
5 -
26
th
Harmonic 0.0 to 999.9x10
22
6 -
28
th
Harmonic 0.0 to 999.9x10
22
7 -
30 th Harmonic 0.0 to 999.9x10 22
8 -
32 nd Harmonic 0.0 to 999.9x10 22
9 -
34 th Harmonic 0.0 to 999.9x10 22
10 -
36 th Harmonic 0.0 to 999.9x10 22
11 -
38 th Harmonic 0.0 to 999.9x10 22
12 -
40 th Harmonic 0.0 to 999.9x10 22
13 - FFT iteration 0 to 32767
