Rockwell Automation 1404-M4_M5_M6_M8 Powermonitor 3000 User Manual, PRIOR to Firmware rev. 3.0 - Manual (Page 230)

Publication 1404-UM001D-EN-E - October 2004
A-56 Powermonitor 3000 Data Tables
Table A.45 Transient Capture Clear/Read-Back Data Select
CSP File No. N45
Remote I/O BT 17
CIP Assy. Inst. 55 (Write), 56 (Read)
No. of Elements 13
User Configurable No
Data Type Integer
Data Access Read / Write
PM3000 Type M8 only
Applies to: Table 45: Transient capture results
Element
No. Modbus
Address Element name Range Default
Value Comment
0 - Password 0 to 9999 0 Required for configuration, -1 for readback select, returns
-1.
1 - Dnet unique write
identifier -32768 to 32767 0 Refer to DeviceNet Unique Write Identifier on page 4-36.
2 - Capture number 0 to 6 1 Refer to Reading Transient Capture Data on page 8-21.
3 - Channel number 1 to 7 1
4 - Block number See page 90 1
5 - Read-back mode 0 to 2 0
6 - Clear command 0 to 3 0
7 - Reserved 0 0
8 - Reserved 0 0
9 - Reserved 0 0
10 - Capture clear status 0 to 63 -
11 - Capture ready status 0 to 63 -
12 - Reserved 0 0
