Publication 1404-UM001D-EN-E - October 2004
Powermonitor 3000 Data Tables A-29
Table A.20 Setpoint Output Actions
Applies to: Refer to Setpoint Setup/Read-Back Select and Status on page A-26
PM3000 Type See table
Param.
# Parameter name M4
M5 M
6 M
8 Comment
0 None • • • No output action, but recorded in the event log and Setpoint status
recorded.
1 Energize relay and set alarm flag 1
• • • Refer to Table A.3 Discrete Data .
2 Energize KYZ and set alarm flag 2
• • •
3 Set alarm flag 3
• • •
4 Set alarm flag 4 • • •
5 Set alarm flag 5 • • •
6 Set alarm flag 6
• • •
7 Set alarm flag 7
• • •
8 Set alarm flag 8
• • •
9 Set alarm flag 9 • • •
10 Set alarm flag 10 • • •
11 Set alarm flag 11 • • •
12 Set alarm flag 12
• • •
13 Set alarm flag 13
• • •
14 Set alarm flag 14
• • •
15 Set alarm flag 15 • • •
16 Set alarm flag 16 • • •
17 Save a trend log record • • • Saves record even if periodic trending is disabled
18 Clear kWh result
• • •
19 Clear kVARh result
• • •
20 Clear kVAh result
• • •
21 Clear Ah result • • •
22 Clear all energy results • • •
