Publication 1404-UM001D-EN-E - October 2004
Powermonitor 3000 EtherNet/IP Device Profile F-9
Class-Specific Service
Execute PCCC Service
The Execute PCCC service is sent by a remote application to perform
a PCCC request. The service accepts the following request parameters,
which represent a completely encapsulated PCCC command:
Table F.18
Service
Code Class/Instance
Usage Service Name
0x4B Instance Execute PCCC
Table F.19 Request Parameters
Name Data Type Parameter
Description Semantics of Values
Length USINT Length of Requestor
ID Number of bytes,
including Length, Vendor,
Serial Number and other
fields.
Vendor UINT Vendor Number of
requester Same as the attribute in
the Device Object of the
same name.
Serial Number UDINT ASA serial number of
requestor Same as the attribute in
the Device Object of the
same name.
Other Product Specific Identifier of user,
task, etc. on the
requester Product specific
CMD USINT Command Byte Refer to PCCC
specification
STS USINT 0 Must be 0 on PCCC
requests
TNSW UINT Transport Word None. Same value must
be returned to requestor.
FNC USINT Function Code (Not
used for all Command
Bytes) Refer to PCCC
specification
PCCC parameters Array of USINT CMD/FNC specific
parameters Refer to PCCC
specification
