Rockwell Automation 1404-M4_M5_M6_M8 Powermonitor 3000 User Manual, PRIOR to Firmware rev. 3.0 - Manual (Page 181)

Publication 1404-UM001D-EN-E - October 2004
Powermonitor 3000 Data Tables A-7
Table A.4 Basic Device Configuration
CSP File No. F10
Remote I/O BT 20
CIP Assy. Inst. 4 (Write), 5 (Read)
No. of Elements 8 (M4, M5), 9 (M6, M8)
User Configurable No
Data Type Floating point
Data Access Read / Write
PM3000 Type See table
Element
No. Modbus
Address Element name M4
M5 M
6 M
8 Range Units Defaul
t
Value Comment
0 40001-2 Password
• • • 0 to 9999
- 0 Valid password required to change
configuration. Returns -1
1 40003-4 Wiring mode • • • 0 to 8 - 6 0 = Delta 3 CT
1 = Delta 2 CT
2 = Direct Delta 3 CT
3 = Direct Delta 2 CT
4 = Open Delta 3 CT
5 = Open Delta 2 CT
6 = Wye
7 = Single Phase
8 = Demo
2 40005-6 Potential transformer (PT)
primary • • • 1.0 to
10,000,000.0
Volts 480.0 The high side of the PT ratio (xxx:xxx)
3 40007-8 PT secondary
• • • 1.0 to 600.0 Volts
480.0 The low side of the PT ratio (xxx:xxx)
4 40009-10 I1/I2/I3 current
transformer (CT) Primary
• • • 1.0 to
10,000,000.0
Amps 5.0 The high side of the CT ratio
(xxx:xxx)
5 40011-12 I1/I2/I3 CT secondary
• • • 1.0 to 5.0
Amps 5.0 The low side of the CT ratio (xxx:xxx)
6 40013-14 I4 CT primary
• • • 1.0 to
10,000,000.0
Amps 5.0 The high side of the I4 CT ratio
(xxx:xxx)
7 40015-16 I4 CT secondary
• • • 1.0 to 5.0
Amps 5.0 The low side of the I4 CT ratio
(xxx:xxx)
8 40017-18 Nominal system voltage
• • 1.0 to
10,000,000.0
Volts 480.0 Value is used in the default Sag and
Swell setpoints. (M6 and M8 only)
