F-10 Powermonitor 3000 EtherNet/IP Device Profile
The DC will respond to the Execute PCCC service with the following
response parameters, which represent a completely encapsulated
PCCC response:
TIP
The Length parameter contains the total length of the
Vendor, Serial Number and Other parameters to
follow. None of these values are actually used by the
PCCC Object, but are instead simply preserved intact
in the associated response.
Table F.20 Response Parameters
Name Data Type Parameter
Description Semantics of Values
Length USINT Length of Requestor
ID Same value as in
request.
Vendor UINT Vendor Number of
requester Same value as in
request.
Serial Number UDINT ASA serial number of
requestor Same value as in
request.
Other Product Specific Identifier of user,
task, etc. on the
requester Same value as in
request.
CMD USINT Command Byte Refer to PCCC
specification
STS USINT Status Byte Refer to PCCC
specification
TNSW UINT Transport Word None. Same value as the
request
EXT_STS USINT Extended Status: not
used for all CMD’s Refer to PCCC
specification
PCCC results Array of USINT CMD/FNC specific
result data Refer to PCCC
specification
TIP
The Length parameter contains the total length of the
Vendor, Serial Number and Other parameters to
follow. None of these values are actually used by
the PCCC Object, but are instead simply preserved
intact in the associated response.
