Rockwell Automation 294E ArmorStart LT EtherNet/IP Version - User Manual User Manual
Page 97
Rockwell Automation Publication 290E-UM001B-EN-P - June 2012
97
Product Commissioning
Chapter 3
UnswitchedVoltageLevel
Unswitched control power voltage — Parameter 12
TripStatus
Bit enumerate trip status — Parameter 16
WarningStatus
Bit enumerate warning status — Parameter 17
Device Input Status Tags
Tag Description/Use
