Rockwell Automation Publication 290E-UM001B-EN-P - June 2012 89
Product Commissioning Chapter 3
Table 14 - Bulletin 294E Consume Assembly/Command Tag Explanation
ASLT_DEMO DCBusVoltage ASLT_DEMO:I.DCBusVoltage INT Decimal
ASLT_DEMO SwitchedVoltageLevel ASLT_DEMO:I.SwitchedVoltageLevel INT Decimal
ASLT_DEMO UnswitchedVoltageLevel ASLT_DEMO:I.UnswitchedVoltageLevel INT Decimal
ASLT_DEMO InternalFanRPM ASLT_DEMO:I.InternalFanRPM INT Decimal
ASLT_DEMO OperatingHours ASLT_DEMO:I.OperatingHours INT Decimal
ASLT_DEMO DriveTemperature ASLT_DEMO:I.DriveTemperature INT Decimal
ASLT_DEMO TripStatus ASLT_DEMO:I.TripStatus INT Binary
ASLT_DEMO WarningStatus ASLT_DEMO:I.WarningStatus INT Binary
Device Name Name Logix Tag Name Data Type Style
Device Output Command Tags Tag Description/Use
RunForward Command VFD forward
RunReverse Command VFD reverse
ResetFault Fault reset
JogForward Command Jog forward per internal frequency
JogReverse Command Jog reverse per internal frequency
Pt00Data If user defined as output, commnd output ON
Pt01Data If user defined as output, commnd output ON
Pt02Data If user defined as output, commnd output ON
Pt03Data If user defined as output, commnd output ON
Pt04Data If user defined as output, commnd output ON
Pt05Data If user defined as output, commnd output ON
Accel2 VFD acceleration ramp 2
Decel2 VFD deceleration ramp 2
FreqCommand Logix command frequency
Pt00DeviceIn Network input to DeviceLogix engine
Pt01DeviceIn Network input to DeviceLogix engine
Pt02DeviceIn Network input to DeviceLogix engine
Pt03DeviceIn Network input to DeviceLogix engine
Pt04DeviceIn Network input to DeviceLogix engine
Pt05DeviceIn Network input to DeviceLogix engine
Pt06DeviceIn Network input to DeviceLogix engine
Pt07DeviceIn Network input to DeviceLogix engine
Pt08DeviceIn Network input to DeviceLogix engine
Pt09DeviceIn Network input to DeviceLogix engine
Pt10DeviceIn Network input to DeviceLogix engine
Pt11DeviceIn Network input to DeviceLogix engine
Pt12DeviceIn Network input to DeviceLogix engine
Pt13DeviceIn Network input to DeviceLogix engine
Pt14DeviceIn Network input to DeviceLogix engine
Pt15DeviceIn Network input to DeviceLogix engine
Int00DeviceIn Network analog input to DeviceLogix engine
