CIP Information

Appendix B

The following common services will be implemented for the Ethernet Link
Object.

4

Get

Interface Counters

Struct of:

In Octets
In Ucast packets
In NUcast packets
In Discards
In Errors
In Unknown Protos
Out Octets
Out Ucast packets
Out NUcast packets
Out Discards
Out Errors

5

Get

Media Counters

Struct of:

Alignment Errors
FCS Errors
Single Collisions
SQE Test Errors
Deferred Transmits
Late Collisions
Excessive Collisions
MAC Transmit Errors
Carrier Sense Errors
Frame Too Long
MAC Receive Errors

6

Get/Set

Interface Control

Struct of:

Control Bits
Forced Interface

Speed

7

Get

Interface Type

USINT

8

Get

Inteface State

USINT

9

Get/Set

Admin State

USINT

10

Get

Interface Label

SHORT_STRING

Instance 1:LS 1
Instance 2:LS 2

Attribute ID

Access Rule

Name

Data Type

Value

Service Code

Implemented for:

Service Name

Class Instance

0x0E

Yes

Yes

Get_Attribute_Single

0x10

No

Yes

Set_Attribute_Single
