36 Rockwell Automation Publication 290E-UM001B-EN-P - June 2012
Chapter 1 Product Overview
Bulletin 290E
With the KeypadMode parameter (parameter 66) set to 1 = Maintained, pressing
the buttons reacts like a maintained switch.
With the KeypadMode parameter (parameter 66) set to 0 = Momentary,
pressing the buttons reacts like a momentary switch.
Bulletin 291E
With the KeypadMode parameter (parameter 66) set to 1 = Maintained, pressing
the buttons reacts like a maintained switch.
With the KeypadMode parameter (parameter 66) set to 0 = Momentary,
pressing the buttons reacts like a momentary switch.
Key Press
Current Mode
OFF HAND AUTO
AUTO Auto Mode — Motor Off — —
HAND If no fault, Motor On — —
OFF — Motor turns Off Motor turns Off
FAULT PRESENT — Motor turns Off Motor turns Off
Key Press
Current Mode
OFF Key HAND AUTO Key
NO KEY PRESSED — Motor Off —
AUTO Auto Mode — Motor Off — —
HAND If no fault, Motor On — —
OFF — Motor Off Motor Off
PROTECTION FAULT PRESENT — Motor Off —
Key Press
Current Mode
OFF HAND AUTO
FWD/REV FWD LED Set REV LED
REV LED Set FWD LED — —
AUTO Auto Mode — Motor Off — —
HAND If no fault, Motor On — —
OFF Ignore Motor Off Motor Off
PROTECTION FAULT PRESENT Ignore Motor Off —
Key Press
Current Mode
OFF HAND AUTO
NO KEY PRESSED — Motor Off —
FWD/REV FWD LED Set REV LED
REV LED Set FWD LED — —
AUTO Auto Mode — Motor Off — —
HAND If no fault, Motor On — —
OFF — Motor Off Motor Off
PROTECTION FAULT PRESENT — Motor Off —
