Rockwell Automation Publication 290E-UM001B-EN-P - June 2012

221

CIP Information

Appendix B

5

Phase U to Gnd

A Phase U to Ground fault detected between drive and motor.

38

6

Phase V to Gnd

A Phase V to Ground fault detected between drive and motor.

39

7

Phase W to Gnd

A Phase W to Ground fault detected between drive and motor.

40

8

Phase UV Short

Excessive current detected between phases U and V.

41

9

Phase UW Short

Excessive current detected between phases U and W.

42

10

Phase VW Short

Excessive current detected between phases V and W.

43

11

Ground Fault

A current path to earth ground at one or more output terminals.

13

12

Stall Trip

The drive is unable to accelerate the motor.

6

13

Switched Power

Indicates the loss of switched control power.

Not available in units with Integrated Power Supply

14

Under Power Trip

Indicates the internal power supply is below its working level.

Available in units with Integrated Power Supply only.

15

Sensor Short

Flags a miswired hardware input point.

16

Output Short

Flags a miswired hardware output point.

17

Fault 17

18

Heatsink Temp

The Heatsink temperature exceeds a predefined value.

8

19

HW Over Current

The drive output current has exceeded the hardware limit.

12

20

SW OverCurrent

Programmed parameter 83 (SW Current Trip) has been exceeded.

63

21

Aux Power Loss

Auxiliary Power was lost or dipped below the minimum threshold.

Not available in units with Integrated Power Supply.

22

Internal Comm

Communication with the internal Power Flex drive has been lost.

71

23

Drive Comm Loss

The RS485 port on the internal Power Flex stopped communicating.

81

24

Power Loss

Drive DC Bus Voltage remained below 85% of nominal bus voltage.

3

25

Under Voltage

DC Bus Voltage fell below the minimum value.

4

26

Over Voltage

DC Bus Voltage exceeded the maximum value.

5

27

MCB EEPROM

This is a major fault which renders the ArmorStart inoperable.

28

Param Sync

The drive and Main Control Board EEPROMS are not in sync.

29

Drive EEPROM

The drive EEPROM checksum checks have failed.

100

30

Hardware Fault

This is a major fault which renders the unit inoperable

31

Fan RMP

The internal cooling fan is not running properly.

32

Power Unit

A major failure has been detected in the drive power section.

70

33

Drive I/O Brd

A failure has been detected in the drive control and I/O section.

122

34

Restart Retries

Automatic fault reset and run retries exceeded.

33

35

Drive Aux In Flt

The drive auxiliary input interlock is open inside the ArmorStart.

2

36

Fault 36

37

Drv Param Reset

Internal Drive Parameters (Parameters > 100) have been defaulted.

48

38

Fault 38

39

Fault 39

40

Unknown Fault

Table 34 - Fault Codes, Fault Text, and Fault Help Strings for Drive Units

Fault

Code

Fault Text

Help Text

PF4M

Fault

Code
