Rockwell Automation Publication 290E-UM001B-EN-P - June 2012 87
Product Commissioning Chapter 3
Table 12 - Default Produce Assembly for Bulletin 294E
ASLT_DEMO Pt14DeviceIn ASLT_DEMO:O.Pt14DeviceIn BOOL Decimal
ASLT_DEMO Pt15DeviceIn ASLT_DEMO:O.Pt15DeviceIn BOOL Decimal
ASLT_DEMO Int00DeviceIn ASLT_DEMO:O.Int00DeviceIn BOOL Decimal
Device Name Name Logix Tag Name Data Type Style
Instance 156 “Drive Status” - Produced Assembly for Bulletin 294 Starters
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Reserved - (name):I.ConnectionFault ➊
1 Reserved - (name):I.ConnectionFault ➊
2 Reserved - (name):I.ConnectionFault ➊
3 Reserved - (name):I.ConnectionFault ➊
4 AtReference NetRefStatus NetControlStatus Ready RunningReverse RunningForward WarningPresent TripPresent
5 BrakeStatus DisconnectClosed KeyPadJogging KeyPadHand KeyPadOff KeyPadAuto DLXEnabled
6 OutputFrequency (Low) (xxx.x Hz)
7 OutputFrequency (High) (xxx.x Hz)
8 Pt05 Pt04 Pt03 Pt02 Pt01 Pt00
9
10 Pt07DeviceOut Pt06DeviceOut Pt05DeviceOut Pt04DeviceOut Pt03DeviceOut Pt02DeviceOut Pt01DeviceOut Pt00DeviceOut
11 Pt15DeviceOut Pt14DeviceOut Pt13DeviceOut Pt12DeviceOut Pt11DeviceOut Pt10DeviceOut Pt09DeviceOut Pt08DeviceOut
12 AnalogDeviceOut (low byte)
13 AnalogDeviceOut (high byte)
14
Param3 — OutputCurrent
15
16
Param 4 — OutputVoltage
17
18
Param 5 — DCBusVoltage
19
20
Param 11 — SwitchedVolts (OutputSourceV, IPS units)
21
22
Param 12 — UnswitchedVolts (SensorSourceV, IPS units)
23
24
Param 13 — InternalFanRPM
25
26
Param 14 — ElapesedRunTime
27
28
Param 15 — DriveTemperature
29
30
Param 16 — TripStatus
31
32
Param 17 — WarningStatus
33
➊ PLC Communication Fault Only
