Instance 154

Instance 154 is the default Output (Consumed) Assembly for Inverter type
(Bulletin 294E) Distributed Starters.

Instance 156

Instance 156 is the Exhaustive Drive Status Assembly Instance

22

Parameter 11 – SwitchedVolts

OutputSourceV (IPS units)

23

24

Parameter 12 – UnswitchedVolts

SensorSourceV (IPS units)

25

26

Parameter 16 – TripStatus

27

28

Parameter 17 – WarningStstus

29

Instance 152 "Starter Stat" – DeviceLogix Produced Assembly for Bulletin 290E/291E Starters

Instance 154 "Drive Cmd" – DeviceLogix Consumed Assembly for Bulletin 294E Starters

Byte

Bit 7

Bit 6

Bit 5

Bit 4

Bit 3

Bit 2

Bit 1

Bit 0

0 JogReverse

JogForward

ResetFault

RunReverse

RunFoward

1 Decel2

Accel2

Out05

Out04

Out03

Out02

Out01

Out00

2

CommandFreq (Low) (xxx.x Hz)

3

CommandFreq (High) (xxx.x Hz)

4

Pt07DeviceIn

Pt06DeviceIn

Pt05DeviceIn

Pt04DeviceIn

Pt03DeviceIn

Pt02DeviceIn

Pt01DeviceIn

Pt00DeviceIn

5

Pt15DeviceIn

Pt14DeviceIn

Pt13DeviceIn

Pt12DeviceIn

Pt11DeviceIn

Pt10DeviceIn

Pt09DeviceIn

Pt08DeviceIn

6

An00DeviceIn (lowbyte)

7

An00DeviceIn (highbyte)

Instance 156 "Drive Status" – Produced Assembly for Bulletin 294E Starters

Byte

Bit 7

Bit 6

Bit 5

Bit 4

Bit 3

Bit 2

Bit 1

Bit 0

0 Reserved

1 Reserved

2

Reserved

3

Reserved

4

AtReference

NetRefStatus

NetControlStatus

Ready

RunningReverse

RunningForward

WarningPresent

TripPresent

5

BrakeStatus

DisconnectClosed

KeyPadJogging

KeyPadHand

KeyPadOff

KeyPadAuto

DLXEnabled

6

Output Frequency (Low) (xxx.x Hz)

7

Output Frequency (High) (xxx.x Hz)

8

Pt05

Pt04

Pt03

Pt02

Pt01

Pt00

9

10

Pt07DeviceOut

Pt06DeviceOut

Pt05DeviceOut

Pt04DeviceOut

Pt03DeviceOut

Pt02DeviceOut

Pt01DeviceOut

Pt00DeviceOut
