Bulletin 290E/291E/294E Programmable Parameters

MotorOLCurrent

Set to the maximum allowable motor current.

Parameter Number

30

Related Parameter

31, 80, 82…83

Access Rule

GET/SET

Data Type

UINT

Group

Motor and Control

Cat. No.

Hp (kW)

Min Amps

Default Amps

Units

x.x Amps

294_FD1P5

0.5 (0.4)

0

1.5

Minimum Value

0

294_FD2P5

1.0 (0.75)

0

2.5

Maximum Value

Cat. No. Dependent

294_FD4P2

2.0 (1.5)

0

3.6

Default Value

Cat. No. Max Output

CurrentLimit

Maximum output current allowed before current limiting occurs

Parameter Number

31

Related Parameters

Access Rule

GET/SET

Data Type

UINT

Group

Motor and Control

Cat. No.

Hp (kW)

Units

x.x Amps

294_FD1P5

0.5 Hp

Min = 0; Max = 2.7; Default = 2.2

Minimum Value

0

294_FD2P5

1.0 Hp

Min = 0; Max = 4.5; Default = 3.7

Maximum Value

Cat. No. Dependent

294_FD4P2

2.0 Hp

Min = 0; Max = 7.5; Default = 6.3

Default Value

Cat. No. Dependent

StopMode

Valid Stop Mode for the Bulletin 294E ArmorStart LT are the following:
0 = RampToStop, “Stop” command clears active fault
1 = Coast to Stop, “Stop” command clears active fault
2 = DCBrake, DC Injection Braking Stop, “Stop” command clears active fault
3 = DCBrakeAuto, DC Injection Stop with Auto Shutoff

Standard DC Injection Braking for value set in Parameter 75 (DC Brake Time)
or
Drive shuts off if current limit is exceeded.

Parameter Number

32

Related Parameters

Access Rule

GET/SET

Data Type

UINT

Group

Motor and Control

Units

Minimum Value

0

Maximum Value

3

Default Value

0
