Rockwell Automation Publication 290E-UM001B-EN-P - June 2012

127

Bulletin 290E/291E/294E Programmable Parameters Chapter 4

Bit

Function:

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

0

— — — — — — — — — — — — — — —

X

Pt00

— — — — — — — — — — — — — —

X

Pt01

— — — — — — — — — — — — —

X

— —

Pt02

— — — — — — — — — — — —

X

— — —

Pt03

— — — — — — — — — — —

X

— — — —

Pt04

— — — — — — — — — —

X

— — — — —

Pt05

X

X

X

X

X

X

X

X

X

X

— — — — — —

Reserved

NetworkStatus

The parameter provides the status
of the network connections.

Parameter Number

9

Access Rule

GET

Data Type

WORD

Group

Basic Status

Units

Minimum Value

0

Maximum Value

0xDF

Default Value

0

Bit

Function:

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

0

— — — — — — — — — — — — — — —

X

ExplicitCnxn

— — — — — — — — — — — — — —

X

IOConnection

— — — — — — — — — — — — —

X

— —

ExplicitCnxnFlt

— — — — — — — — — — — —

X

— — —

IOCnxnFault

— — — — — — — — — — —

X

— — — —

IOCnxnIdle

— — — — — — — — — —

X

— — — — —

Reserve

— — — — — — — — —

X

— — — — — —

DLREnabled

— — — — — — —

X

— — — — — — —

DLRFlt

X

X

X

X

X

X

X

X

— — — — — — — —

Reserved

DLXControlStatus

The parameter provides the DeviceLogix
Control Status.
0 = Controlled in Logix Programs
1 = Controlled in local DLX programs.

Parameter Number

10

Access Rule

GET

Data Type

UINT

Group

Basic Status

Units

Minimum Value

0

Maximum Value

0x1FFF

Default Value

0
