background image

Rockwell Automation Publication 290E-UM001B-EN-P - June 2012

233

Using DeviceLogix™ Appendix C

19.

Go to the pull-down menu in the right corner of the toolbar and select
Download”.

Note:

Ensure that the PLC key switch is in the Program position. If in any other

position, the download will not occur and an error will be generated.

20.

Press “OK” when told the download was successful.

21.

Now from the same pull-down menu select “Logic Enable On.”

22.

The ArmorStart is now programmed and the logic is Active.

Table 36 - DeviceLogix Input and Output Variables

Element Type

Bulletin 290E

Bulletin 291E

Bulletin 294E

Consumed Network Data

PT00DeviceIn

PT00DeviceIn

PT00DeviceIn

PT15DeviceIn

PT15DeviceIn

PT15DeviceIn

Discrete Input Points

PT00

PT00

PT00

PT00

PT00

PT00

Discrete Output Points

RunForward

RunForward

RunForward

RunReverse

RunReverse

Out00

Out00

Out00

Out05

Out05

Out05

JogForward

JogReverse

Produced Network Data

Pt00DeviceOut

Pt00DeviceOut

Pt00DeviceOut

Pt15DeviceOut

Pt15DeviceOut

Pt15DeviceOut

ResetFault

ResetFault

ResetFault

MotionDisable

MotionDisable

MotionDisable

ForceSnapshot

ForceSnapshot

ForceSnapshot

UserDefinedFault

UserDefinedFault

UserDefinedFault

KeypadDisable

KeypadDisable

KeypadDisable

Accel2

Decel2

BrakeRelease
