Rockwell Automation Publication 290E-UM001B-EN-P - June 2012

199

CIP Information

Appendix B

Instance 101

Instance 101 is the Configuration Assembly for Bulletin 294E units.

36

72

StallEnableTime

74

37

74

StallTripLevel

75

38

76

ULInhibitTime

76

39

78

ULTripDelay

77

40

80

ULTripLevel

78

41

82

ULWarnLevel

79

Instance 101 for Bulletin 294E Starters

Member Index

Byte Offset

Name

Parameter Instance

0

0

AssemblyRevision

N/A

1

2

AssemblyRevision

N/A

2

4

MotorNPVolts

28

3

6

MotorNPHertz

29

4

8

MotorOLCurrent

30

5

10

CurrentLimit

31

6

12

StopMode

32

7

14

SpeedReference

33

8

16

MinimumFreq

34

9

18

MaximumFreq

35

10

20

AccelTime1

36

11

22

DecelTime1

37

12

24

SCurvePercent

38

13

26

JogFrequency

39

14

28

JogAccelDecel

40

15

30

ProtFltResetMode

41

16

32

ProtectFltEnable

42

17

34

WarningEnable

43

18

36

RunNetFltAction

45

19

38

RunNetFaultValue

46

20

40

RunNetIdleAction

47

21

42

RunNetIdleValue

48

22

44

IOPointConfigure

49

23

46

FilterOffOn

50

24

48

FilterOnOff

51

25

50

OutProtFltState

52

26

52

OutProtFltValue

53

Instance 100 for Bulletin 290E/291E Starters

Member Index

Byte Offset

Name

Parameter Instance
