Bulletin 290E/291E/294E Programmable Parameters Chapter 4

Figure 55 - Overload Trip Curves

ATTENTION: The bus regulator mode function is extremely useful for
preventing nuisance overvoltage faults resulting from aggressive decelerations,
overhauling loads, and eccentric loads. However, it can also cause either of the
following two conditions to occur.

1. Fast positive changes in input voltage or imbalanced input voltages can cause
uncommanded positive speed changes;

2. Actual deceleration times can be longer than commanded deceleration times.
However, a "Stall Fault" is generated if the drive remains in this state for 1 minute.
If this condition is unacceptable, the bus regulator must be disabled.

MotorOLSelect

Drive provides Class 10 motor overload
protection. Sets the derating factor for I

2

T

motor overload function.
0 = NoDerating
1 = MinDerating
2 = MaxDerating

Parameter Number

82

Related Parameters

29, 30

Access Rule

GET/SET

Data Type

UINT

Group

Advanced Config.

Units

Minimum Value

0

Maximum Value

2

Default Value

0

Min. Derate

0

80

100

60

40

20

% of Motor Overload Current (P30)

No Derate

0

80

100

60

40

20

% of Motor Nameplate Hertz (P29)

% of Motor Overload Current (P30)

% of Motor Nameplate Hertz (P29)

% of Motor Overload Current (P30)

% of Motor Nameplate Hertz (P29)

Max. Derate

0

80

100

60

40

20

0

200

175

150

125

100

75

50

25

0

200

175

150

125

100

75

50

25

0

200

175

150

125

100

75

50

25

SWCurrentTrip

Enables/disables a software instantaneous
(within 100 ms) current trip.

For 0.5 Hp units – Min = 0; Max = 3.0; Default = 0
For 1.0 Hp units – Min = 0; Max = 5.0; Default = 0
For 2.0Hp units – Min = 0; Max = 8.4; Default = 0

Parameter Number

83

Related Parameter

30

Access Rule

GET/SET

Data Type

UINT

Group

Advanced Config.

Units

x.x Amps

Minimum Value

0.0

Maximum Value

Hp Dependent

Default Value

0.0 (Disabled)
