5 Parameter reference
5.1 Parameter list | C15891
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C15891
C15892
Parameter | Name:
C15891 | Log function
Data type: UNSIGNED_8
Index: 8684
d
= 21EC
h
From V1.4
Setting of the logging response (trigger condition).
 Logbook function in the SM301
Selection list (Lenze setting printed in bold) Info
0 Logging active Logging always active
1 Logging stopped Logging switched off.
2 Stop logging in the event of an error Logging is stopped when an error occurs.
3 Stop logging in the case of STO
Logging is stopped when STO occurs.
4 Stop logging in the case of SS1 Logging is stopped when SS1 occurs.
5 Stop logging in the case of SS2 Logging is stopped when SS2 occurs.
 Read access  Write access  CINH  PLC-STOP  No transfer Scaling factor: 1
Parameter | Name:
C15892 | Log time
Data type: UNSIGNED_32
Index: 8683
d
= 21EB
h
From V1.4
Time of the log entry.
 Logbook function in the SM301
Display range (min. value | unit | max. value)
0 ms 4294967295
Subcodes Info
C15892/1 Log time n
C15892/2 Log time n-1
C15892/3 Log time n-2
C15892/4 Log time n-3
C15892/5 Log time n-4
C15892/6 Log time n-5
C15892/7 Log time n-6
C15892/8 Log time n-7
C15892/9 Log time n-8
C15892/10 Log time n-9
 Read access  Write access  CINH  PLC-STOP  No transfer Scaling factor: 1
