5 Parameter reference
5.1 Parameter list | C15815
98
Lenze · SM301 safety module · Parameter setting & configuration · DMS 2.3 EN · 11/2013 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C15815
C15820
C15821
C15822
C15890
Parameter | Name:
C15815 | Service code
Data type: UNSIGNED_16
Index: 8760
d
= 2238
h
Status display of the module LEDs.
Display range
(min. value | unit | max. value)
0 65535
 Read access  Write access  CINH  PLC-STOP  No transfer Scaling factor: 1
Parameter | Name:
C15820 | Internal actual position value
Data type: INTEGER_32
Index: 8755
d
= 2233
h
Display of internal position values.
Display range
(min. value | unit | max. value)
-2147483648 Incr. 2147483647
Subcodes Info
C15820/1 Internal actual position value pSM
C15820/2 Internal actual position value pGG
 Read access  Write access  CINH  PLC-STOP  No transfer Scaling factor: 1
Parameter | Name:
C15821 | Service code
Data type: INTEGER_16
Index: 8754
d
= 2232
h
Currently monitored speed value of the ramp monitoring.
• Displayed value only valid if SS1 or SS2 are active with ramp monitoring.
Display range
(min. value | unit | max. value)
-16000 rpm 16000
 Read access  Write access  CINH  PLC-STOP  No transfer Scaling factor: 1
Parameter | Name:
C15822 | Service code
Data type: INTEGER_16
Index: 8753
d
= 2231
h
Minimum difference between actual speed value and monitored ramp.
• The value is maintained until a ramp monitoring is restarted.
Display range (min. value | unit | max. value)
-16000 rpm 16000
 Read access  Write access  CINH  PLC-STOP  No transfer Scaling factor: 1
Parameter | Name:
C15890 | Current time
Data type: UNSIGNED_32
Index: 8685
d
= 21ED
h
From V1.4
Relative time for use in the logbook.
 Logbook function in the SM301
Display range
(min. value | unit | max. value)
0 ms 4294967295
 Read access  Write access  CINH  PLC-STOP  No transfer Scaling factor: 1
