5 Parameter reference
5.1 Parameter list | C15032
76
Lenze · SM301 safety module · Parameter setting & configuration · DMS 2.3 EN · 11/2013 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C15032
C15033
Parameter | Name:
C15032 | SD-In free assignment
Data type: UNSIGNED_8
Index: 9543
d
= 2547
h
Assignment of a safety function to a safe input.
• Only possible if the sensor function "Free assignment" is set for the safe input in C15031 .
 Safe inputs
Selection list Info
0 STO  Safe torque off
1 SS1  Safe stop 1
2 SS2  Safe stop 2
3 SLS1  Safely limited speed 1
4 SLS2  Safely limited speed 2 (from V1.1)
5 SLS3  Safely limited speed 3 (from V1.1)
6 SLS4  Safely limited speed 4 (from V1.1)
7 SDIpos  Safe positive direction (from V1.3)
8 SDIneg  Safe negative direction (from V1.3)
9 No response No (local) safety function assigned.
• Function test and monitoring of the discrepancy time
are active.
• The status of the input is transferred to the control via
the safety bus (if parameterised).
Subcodes Lenze setting Info
C15032/1 0: STO SD-In1 free assignment
C15032/2 0: STO SD-In2 free assignment
C15032/3 0: STO SD-In3 free assignment
C15032/4 0: STO SD-In4 free assignment
 Read access  Write access  CINH  PLC-STOP  No transfer Scaling factor: 1
Parameter | Name:
C15033 | SD-In discrepancy time
Data type: UNSIGNED_16
Index: 9542
d
= 2546
h
Maximum time for which both channels of a safe input may have non-equivalent states without the safety system
detecting an error.
 Safe inputs
Setting range (min. value | unit | max. value)
0 ms 30000
Subcodes Lenze setting Info
C15033/1 10 ms SD-In1 discrepancy time
C15033/2 10 ms SD-In2 discrepancy time
C15033/3 10 ms SD-In3 discrepancy time
C15033/4 10 ms SD-In4 discrepancy time
 Read access  Write access  CINH  PLC-STOP  No transfer Scaling factor: 1
