3
Safe configuration
3.8
Safe output
40
Lenze · SM301 safety module · Parameter setting & configuration · DMS 2.3 EN · 11/2013 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
3.8.2
Case study 2: "Signalling"
Switching condition
The following switching condition is to be implemented for the safe output SD-Out1:
• Safe signalling is carried out (SD-Out1 in ON state) if
• the power supply for the motor is safely interrupted (STO active)
• AND NO error is active (Error active).
[3-2]
Logic operation for case study "Signalling"
Required parameter setting for SD-Out1
1. Set the following switching condition to "Positive logic":
• STO is active
2. Set the following switching condition to "Negative logic":
• Fault active
3. Set all other switching conditions to "Not evaluated".
4. Set logic function to "AND".
5. If a safety bus has been parameterised:
• The "SD-Out1" bit of the safety control is considered in the ANDing.
• Hide the "SD-Out1" bit via the "S bus: Filter control data" parameter to suppress this access.
SD-Out1 in ON state
STO active
Error active
&
