6 Error messages
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
SLS4: Nlim4 exceeded [0x012f0065]
SLS/SMS: Error stop not executed [0x012f0066]
SDIpos: Wrong direction [0x012f0067]
SDIneg: Wrong direction [0x012f0068]
SMS: Nmax exceeded [0x012f0069]
Module ID (decimal) Error ID (decimal)
303: SM301 safety module 101
Response (Lenze setting printed in bold)
 None  System error  Error  Fault  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
The drive has exceeded the limited speed (SLS4). • Adapt the speed-dependent parameters in the drive.
• Increase speed threshold Nlim.
Module ID (decimal) Error ID (decimal)
303: SM301 safety module 102
Response (Lenze setting printed in bold)
 None  System error  Error  Fault  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
The drive has exceeded the limited speed (SLS1-4) or the
maximum speed (SMS) and not responded adequately
within the maximum response time.
• Adapt the speed-dependent parameters in the drive.
• Increase parameter for the maximum response time.
Module ID (decimal) Error ID (decimal)
303: SM301 safety module 103
Response (Lenze setting printed in bold)
 None  System error  Error  Fault  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
The drive has exceeded the positive monitored direction
(SDIpos).
• Adapt controller parameterisation.
• Increase SDI tolerance threshold.
Module ID (decimal) Error ID (decimal)
303: SM301 safety module 104
Response (Lenze setting printed in bold)
 None  System error  Error  Fault  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
The drive has exceeded the negative monitored direction
(SDIneg).
• Adapt controller parameterisation.
• Increase SDI tolerance threshold.
Module ID (decimal) Error ID (decimal)
303: SM301 safety module 105
Response (Lenze setting printed in bold)
 None  System error  Error  Fault  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
The drive has exceeded the monitored maximum speed
(SMS.
• Limit maximum speed in drive.
• Adapt parameterisation value.
