3 Safe configuration
3.9 Safety functions
42
Lenze · SM301 safety module · Parameter setting & configuration · DMS 2.3 EN · 11/2013 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Short overview of "Safety functions  Safe stop" parameter group:
3.9.1.1 Priorisation
Stop functions with priority influence the process of already started subordinated functions.
1. Safe torque off (STO)
• The STO function has the highest priority and thus takes priority over all other functions.
Functions already started (e.g. SS1 or SS2) are cancelled and the drive is switched off.
2. Safe stop 1 (SS1)
• The SS1 function has priority over SS2. Taking the stopping time set for SS1 and SS2 and for
the SS1 mode (from SM301 V1.3) into consideration, the drive is switched to torque-free
operation.
3. Monitoring functions
• The monitoring functions have the same priorities. They can also be executed parallel to the
stop function.
Parameter Info Lenze setting
Value Unit
C15205 SSE: Emergency stop function STO
C15300/1 Restart behaviour - STO, SS1 Acknowledged restart
C15300/2 Restart behaviour - SS2, SOS Acknowledged restart
C15305 SS1, SS2: Stopping time 0 ms
C15306 SS1 mode * STO after stopping time
C15307 SS1: STO delay after n=0 * 0 ms
C15308 SS2 mode * SOS after stopping time
C15310 Speed window (n=0) 0 rpm
C15311 SOS: Tolerance margin (delta p=0) * 0 Incr.
C15315 SS1, SS2: Ramp monitoring ** Ramp monitoring activated
C15316 SS1, SS2: Ramp - S-ramp time ** 0 %
C15317 SS1, SS2: Ramp - start-offset ** 0 %
* From SM301 V1.3 ** From SM301 V1.4
