6 Error messages
122
Lenze · SM301 safety module · Parameter setting & configuration · DMS 2.3 EN · 11/2013 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
New parameter set deleted [0x012f00a0]
New safe parameter set loaded [0x012f00a1]
Memory module - parameter set access error [0x012f00a2]
Different parameter sets [0x012f00a3]
Module ID (decimal) Error ID (decimal)
303: SM301 safety module 160
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
The parameter set has been deleted via the safe
parameterisaiton in the Engineer.
--
Module ID (decimal) Error ID (decimal)
303: SM301 safety module 161
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
New parameter set has been loaded via the safe
parameterisation in the Engineer or by actuating the
module button at the safety module.
--
Module ID (decimal) Error ID (decimal)
303: SM301 safety module 162
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
An error has been detected when accessing the safe
parameter set in the memory module.
Carry out a general reset. Transfer the safe parameter set
into the safety module.
Module ID (decimal) Error ID (decimal)
303: SM301 safety module 163
Response (Lenze setting printed in bold)
 None  System error  Error  Fault  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Different parameter sets on the memory module and on
the safety module.
Transfer the safe parameter set via the Engineer into the
safety module. Parameter set acceptance from the
memory module using the module button at the safety
module.
