5 Parameter reference
5.1 Parameter list | C15052
80
Lenze · SM301 safety module · Parameter setting & configuration · DMS 2.3 EN · 11/2013 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C15052
Parameter | Name:
C15052 | SD-Out switching condition
Data type: BITFIELD_32
Index: 9523
d
= 2533
h
Bit-coded selection of the conditions for switching the safe output.
 Safe output
Setting range
0x00000000
0xFFFFFFFF
Value is bit-coded: ( = bit set) Info
Bit 0  SOS monitored Safe operating stop is monitored.
Bit 1  SOS monitored - neg. logic Safe operating stop is not monitored.
Bit 2  SLS1 monitored Safely limited speed 1 is monitored.
Bit 3  SLS1 monitored - neg. logic Safely limited speed 1 is not monitored.
Bit 4  SLS2 monitored Safely limited speed 2 is monitored (from V1.1)
Bit 5  SLS2 monitored - neg. logic Safely limited speed 2 is not monitored. (from V1.1)
Bit 6  SLS3 monitored Safely limited speed 3 is monitored (from V1.1)
Bit 7  SLS3 monitored - neg. logic Safely limited speed 3 is not monitored (from V1.1)
Bit 8  SLS4 monitored Safely limited speed 4 is monitored (from V1.1)
Bit 9  SLS4 monitored - neg. logic Safely limited speed 4 is not monitored (from V1.1)
Bit 10  SDIpos monitored Safe positive direction is monitored (from V1.3)
Bit 11  SDIpos observed neg. logic Safe positive direction is not monitored (from V1.3)
Bit 12  SDIneg monitored Safe negative direction is monitored (from V1.3)
Bit 13  SDIneg observed neg. logic Safe negative direction is not monitored (from V1.3)
Bit 14  SSE active  Emergency stop function
Bit 15  SSE active - neg. logic  Emergency stop function
Bit 16  SD-In1 active  Safe inputs
Bit 17  SD-In1 active - neg. logic  Safe inputs
Bit 18  SD-In2 active  Safe inputs
Bit 19  SD-In2 active - neg. logic  Safe inputs
Bit 20  SD-In3 active  Safe inputs
Bit 21  SD-In3 active - neg. logic  Safe inputs
Bit 22  SD-In4 active  Safe inputs
Bit 23  SD-In4 active - neg. logic  Safe inputs
Bit 24  Reserved
Bit 25  Reserved
Bit 26  OMS active
 Safe operation mode selector (from V1.1)
Bit 27  OMS active - neg. logic  Safe operation mode selector (from V1.1)
Bit 28  Reserved
Bit 29  Reserved
Bit 30  Fault active
Bit 31  Error active - neg. logic
Subcodes Lenze setting Info
C15052/1 0x00000000 SD-Out1 switching condition
 Read access  Write access  CINH  PLC-STOP  No transfer
